ACADEMY : 13296

1:35 US Army M60A2 PATTON Tank - ACADEMY

1:35 US Army M60A2 PATTON Tank - ACADEMY

Regular price £33.49 GBP
Regular price £39.99 GBP Sale price £33.49 GBP
Sale Sold out
Tax included. Shipping calculated at checkout.

The M60 is an American second generation main battle tank. During the early 1960s there was some debate regarding the future of main tank weaponry, largely focusing on conventional kinetic energy rounds versus missiles. In the early 1960s it was generally accepted that the maximum effective range of the M68 gun was between 1800 and 2000 meters. The XM-13 missile system had proven itself viable, obtaining over 90% first round accuracy up to 4000 meters. But the development of a main-battle tank variant was bogged down by having too many design proposals. In response, studies were made in August 1961 to retrofit existing M60 tanks with a weapon capable of firing both conventional HEAT (High-Explosive Anti-Tank) rounds and launching ATGMs (Anti-Tank Guided-Missiles). During the development of the M60A2, three different turret types were considered, the Type A, Type B and Type C. The Type A turret would be constructed based on the T95E7 turret and then further modified and produced as the Type B standard.

The M60A2 featured a unique low profile turret, mounting the M162 Gun/Launcher that drastically reduced the turret's frontal arc in comparison to the A1's. It consisted of a large disk with a narrow channel in the center with each crew member in the turret having their own hatch. The gunner and loader were located to the right and left of the gun, respectively, and the commander was in a turret basket up and behind the main gun. The M162 gun was fully stabilized in both turret traverse and gun elevation using the same upgrade kit as the M60A1 AOS, allowing the gunner to effectively scan the battlefield while the tank was in motion. This system could be used by the gunner to engage targets with unguided M409 rounds while the vehicle was in motion, but the tank had to remain stationary when firing and tracking an MGM-51 missile. The turret interior also received Kevlar spall liners. Four M226 smoke grenade launchers were mounted on each side of the turret bustle. Additionally there was a mounting point to the left of the turret for an AN/VSS-1(V)1 Infrared Spotlight and M19E1 IR periscope providing first generation night vision for night operations. A basket was fitted to the rear of the turret to stow the spotlight when not in use. Late production versions replaced the bore evacuator with the Closed-Bore Scavenger System (CBSS), a compressed air system that pushed the fumes and gasses out of the muzzle when the breach was opened. Initial production M60A2s used the M60A1 hull powered by an AVDS-1790-2A TLAC engine, CD-850-5 cross-drive transmission and the T97 track assembly. Many of these hulls were later upgraded to the RISE standard.
